Wiggens은 내구성과 우수한 제품 성능을 갖춘 최고 품질의 일반 실험실 장비, 분석 장비 및 화학 반응 솔루션을 제공합니다.
Features
• Brushless DC motor, 장기 실험용으로 매우 적합
• 완벽히 밀폐되고 작은 사이즈의 메탈 케이스
• 스마트하고 편리한 on-touch 컨트롤
• TFT 스크린으로 설정된 속도와 실제 속도, 회전력 등을 실시간으로 확인 가능
• 쉽게 교체 가능한 키리스척
• 정확한 속도 조절
• 용액의 점도 변화에도 변함없이 유지되는 설정속도
• 쉽고 시간이 단축되는 임펠러 조절
• 디지털과 아날로그 인터페이스 모두 제공
• 컴퓨터 소프트웨어를 통해 모니터링 및 제어 가능
매끈한 디자인을 통해
간편한 높이 조절과 임펠러 조절
정확한 속도 조정
(속도 : 20 ~ 3,000rpm)
장기 실험용으로 적합한
Brushless DC motor
TFT Display
실시간 확인 가능
쉬운 사용
노브를 이용한 On-touch 컨트롤
RS232 / RS485
인터페이스 장착
Keyless chuck
(Climping range : 0.5 ~10mm)
High Torque / High Speed
고속으로 균일하고 높은 품질의 결과
Technical Specification
Model | WB3000-D | WB1800-D | WB6000-D |
Order No. | 100400 | 100600 | 100800 |
Speed range [rpm] 1) | 30~600 (I) 601~3000 (II) | 20~360 (I) 361~1800 (II) | 60~1200 (I) 1201~6000 (II) |
Setting accuracy speed [rpm] | 1 | 1 | 1 |
Deviation of speed measurement n > 300rpm | ±3 % | ±3 % | ±3 % |
Speed Display | TFT display | TFT display | TFT display |
Clockwise or counterclockwise of stirring | Yes | Yes | Yes |
Speed setting | Touch key and turning knob | Touch key and turning knob | Touch key and turning knob |
Power [W] | 150 | 150 | 150 |
Motor principle | Brushless DC motor | Brushless DC moto | Brushless DC motor |
Torque max. at stirring shaft [N-cm] 2) | 339(I) / 68(II) | 563(I) / 113(II) | 170(I) / 34(II) |
Stirring element fastening | Keyless chuck, easy to install and replace the shaft. | Keyless chuck, easy to install and replace the shaft. | Keyless chuck, easy to install and replace the shaft. |
Chuck range diameter [mm] | 0.5~10 | 0.5~10 | 0.5~10 |
Hollow shaft, inner diameter [mm] | 10.2 | 10.2 | 10.2 |
Fastening on stand | Extension arm | Extension arm | Extension arm |
Extension arm diameter [mm] | 13 | 13 | 13 |
Extension arm length [mm] | 124 | 124 | 124 |
Housing material | Cast aluminum coating | Cast aluminum coating | Cast aluminum coating |
RS232 / RS485 interface | Yes | Yes | Yes |
Dimensions (W x H x D) | 200 x 95 x 230 | 200 x 95 x 230 | 200 x 95 x 230 |
Weight [kg] | 5 | 5 | 5 |
Power supply | 100~240VAC,50/60Hz | 100~240VAC,50/60Hz | 100~240VAC,50/60Hz |
1) 이 시리즈에는 두 가지 등급의 교반 속도가 있습니다. 저속등급은 더 높은 토크를 제공하며, 화학 반응 시스템에 적합하고, 고속등급은 샘플 전처리에 적합합니다.
설정된 속도에 따라 두 속도 등급 간에 자동으로 전환할 수 있습니다.
2) 두 속도 범위는 각각 다른 최대 토크에 해당합니다.
Packages
Package 1
Overhead stirrer, WH22-D Support Stand
Package 2
Overhead stirrer, WH22-D Support Stand,
and 9004 impeller
Package 3
Overhead stirrer, WH22-D Support Stand,
and 5.240.8.2 PTFE impeller
